White 2.08 inch Graphic OLED Display Panel 256x64 Parallel/SPI/I2C
- Buy 10 for US$10.33 each and save 3%
- Buy 30 for US$10.03 each and save 6%
- Buy 50 for US$9.74 each and save 8%
- Buy 100 for US$9.44 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
White 2.08 inch Graphic OLED Display Panel 256x64 Parallel/SPI/I2C
US$10.62
-
8051 Microcontroller Development Board for OLED Display ER-OLED0208-1
US$22.26
-
Total price
Description
ER-OLED0208-1W is the graphic OLED display panel made of 256x64 individual white OLED pixels,diagonal is only 2.08 inch.The controller ic SH1122, communicates via 4-wire serial interface. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the connector type,we offer optional zif connector(fpc connector).
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,Controller,Connector
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
2.08 inch 256x64 Pixels OLED Display Module Datasheet | 1.1 | English | Feb-12-2020 |
919K |
|
Controller IC SH1122 Datasheet | 1.0 | English | Jul-01-2012 | 370K |
|
14 Pins 0.5mm Pitch ZIF Connector (FPC Connector) Datasheet | 1.0 | English | Jul-26-2012 | 862K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
Dec-10-2019
|
92K | |
 |
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0190 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
| Part Number | ER-OLED0208-1W |
| Display Format | 256x64 Dots |
| Interface | 4-wire SPI |
| IC or Equivalent | SH1122 |
| Appearance | White on Black |
| Diagonal Size | 2.08“ |
| Connection | Plug-in FPC |
| Outline Dimension | 60.50(W)x19.00(H)x1.6(T)mm |
| Visual Area | 53.18x14.78mm |
| Active Area | 51.18(W)x12.78(H)mm |
| Dot (Pixel) Size | 0.18x0.18mm |
| Dot (Pixel) Pitch | 0.20x0.20mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Viewing Angle Range | Free |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~85℃ |
-
Mirco Costantini
2023-02-28 13:19:27
Is this display available with the I2C interface version?
1 answer-
Sajay Peng
2023-03-01 03:41:35
Sorry we don't have the same display with IIC interface, For this kind of display with grayscale, IIC communication speed is quite slow, So few customers are using IIC and we are not intended to offer such an option, Thanks.
-
