Square 1.44 inch 128x128 TFT LCD Display with Breakout Board
US$2.80
- Buy 10 for US$2.73 each and save 3%
- Buy 30 for US$2.66 each and save 5%
- Buy 50 for US$2.58 each and save 8%
- Buy 100 for US$2.51 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
Square 1.44 inch 128x128 TFT LCD Display with Breakout Board
US$2.80
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
Total price
Description
ER-TFTM1.44-3 is square 1.44 inch TFT LCD display with breakout board, offering a crisp 128x128 pixel resolution. It excels in display quality, providing a normal viewing angle, and can be effortlessly controlled by a range of MCUs, including 8051, PIC, AVR, ARDUINO, ARM, and Raspberry PI. This module is the perfect choice for embedded systems, industrial devices, security equipment, and handheld devices that demand high-quality and vibrant visuals. It incorporates a hassle-free 4-wire serial SPI interface and is equipped with the ST7735S controller.
For this product, we have also meticulously prepared interfacing documents, libraries, and examples specifically tailored for the Arduino Due, Mega 2560, Uno, Nano, as well as the Raspberry Pi and Raspberry Pi Zero. This ensures seamless integration and easy control for users working with these popular platforms.
Datasheet for Display Module
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFTM1.44-3_Datasheet | English |
Feb-24-2024 |
1.6M |
|
Controller ST7735S Datasheet | English | Nov-11-2011 | 3.0M |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Mar-11-2024 | 110K |
Tutorial- Raspberry Pi
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
Raspberry Pi Library and Example | English | Mar-11-2024 | 480K |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Mar-11-2024 | 115K |
| Gross Weight (kg) | 0.0240 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
| Part Number | ER-TFTM1.44-3 |
| Display Format | 128x128 Pixels (Dots) |
| Interface | 4-wire SPI |
| IC or Equivalent | ST7735S |
| Appearance | RGB |
| Diagonal Size | 1.44“ |
| Connection | Pin Header |
| Outline Dimension | 30.00(W)x46.50(H)mm |
| Visual Area | 26.50x27.50mm |
| Active Area | 25.50(W)x26.50(H)mm |
| Dot (Pixel) Pitch | 0.119x0.207mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 4K/65K/262K |
| Viewing Angle Range | Left:70.0 , Right:70.0 , Up:50.0 , Down:70.0 degree |
| Brightness(Typ) | 250cd/m2 |
| Power Supply(Typ) | 3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
