SPI Green 20x2 Character OLED Display Module for Arduino,Raspberry Pi
- Buy 10 for US$19.80 each and save 3%
- Buy 30 for US$19.23 each and save 6%
- Buy 50 for US$18.66 each and save 8%
- Buy 100 for US$18.10 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
SPI Green 20x2 Character OLED Display Module for Arduino,Raspberry Pi
US$20.36
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$11.80
-
Total price
Description
ER-OLEDM2002-2G is the green character OLED display module made of 20 characters wide,2 rows in green color the with breakout board,The controller ic US2066, communicates via 6800/8080 4-bit and 8-bit parallel interface and I2C/4-wire serial interface,Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,nano and for raspberry pi or raspberry pi zero.For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,Controller IC
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-OLEDM2002-2_Datasheet | English | May-26-2023 | 705K |
 |
ER-OLEDM2002-2_3D Model | English | Aug-26-2023 | 560K |
|
Controller IC US2066 Datasheet | English | Jul-07-2017 | 1.1M |
Tutorial - Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | May-30-2023 |
9K
|
|
Interfacing I2C,4Wire-SPI Serial OLED Display Module to Arduino | English | Jun-02-2023 | 206K |
Tutorial - Raspberry Pi
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
Raspberry Pi Library and Example | English | Jun-08-2023 | 38K |
|
Interfacing I2C OLED Display Module to Raspberry Pi | English | Jun-08-2023 | 146K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
May-30-2023
|
10K |
| Gross Weight (kg) | 0.0410 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-OLEDM2002-2G |
| Display Format | 20x2 Character |
| Interface | I2C, 4-wire SPI, 6800 4-bit Parallel , 6800 8-bit Parallel , 8080 4-bit Parallel , 8080 8-bit Parallel |
| IC or Equivalent | US2066 |
| Appearance | Green on Black |
| Diagonal Size | 2.93" |
| Connection | Pin Header |
| Outline Dimension | 116.00(W)x37.00(H)x9.7(T)mm |
| Visual Area | 75.52x13.52mm |
| Active Area | 73.52(W)x11.52(H)mm |
| Dot (Pixel) Size | 0.62x0.67mm |
| Dot (Pixel) Pitch | 0.65x0.70mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Viewing Angle Range | Free |
| Brightness(Typ) | 120cd/m2 |
| Power Supply(Typ) | 5V |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~85℃ |
