Small 0.42 inch White 72x40 OLED Display Module,SSD1315,Serial SPI
US$0.86
- Buy 10 for US$0.83 each and save 3%
- Buy 30 for US$0.81 each and save 6%
- Buy 50 for US$0.79 each and save 8%
- Buy 100 for US$0.77 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
Small 0.42 inch White 72x40 OLED Display Module,SSD1315,Serial SPI
US$0.86
-
8051 Microcontroller Development Board for OLED Display ER-OLED0.42-2
US$22.26
-
Total price
Description
ER-OLED0.42-2W is the graphic OLED display panel made of 72x40 individual white OLED pixels diagonal is only 0.42 inch.The controller ic SSD1315, communicates via 4-wire SPI interface,thanks to controller's built-in voltage generation,only a single 3.3V power supply is needed. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the connector type,we offer optional zif connector(fpc connector).
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-OLED0.42-2_Datasheet | English | Mar-26-2025 |
679K
|
|
16 Pins 0.5mm Pitch ZIF Connector (FPC Connector) | English | Apr-21-2025 | 251K |
|
Controller IC SSD1315_Datasheet | English | May-16-2017 |
1.5M
|
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Mar-29-2024 | 182K |
 |
N/A | N/A |
N/A |
| Gross Weight (kg) | 0.0180 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2025. |
| Part Number | ER-OLED0.42-2W |
| Display Format | 72x40 Dots |
| Interface | 4-wire SPI |
| IC or Equivalent | SSD1315 |
| Appearance | White on Black |
| Diagonal Size | 0.42“ |
| Connection | Plug-in FPC |
| Outline Dimension | 12.00(W)x11.00(H)x1.2(T)mm |
| Visual Area | 10.196x6.18mm |
| Active Area | 9.19(W)x5.18(H)mm |
| Dot (Pixel) Size | 0.12x0.13mm |
| Dot (Pixel) Pitch | 0.11x0.10mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Viewing Angle Range | Free |
| Brightness(Typ) | 80cd/m2 |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~80℃ |
