Serial SPI I2C 1602 Blue 16x2 OLED Character Display
- Buy 10 for US$13.52 each and save 3%
- Buy 30 for US$13.11 each and save 6%
- Buy 50 for US$12.70 each and save 9%
- Buy 100 for US$12.30 each and save 12%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-OLED1602-4B is the character OLED display module made of 16 characters wide,2 rows in blue color.The controller ic US2066, communicates via 6800/8080 4-bit and 8-bit parallel interface and I2C/3-wire/4-wire serial interface. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the soldering type,no need connector.Just solder the FPC on your PCB directly.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,Controller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
16x2 Character OLED Display Module Datasheet | 1.0 | English | Aug-01-2014 |
2.1M
|
|
Controller IC US2066 Datasheet | 1.0 | English | Jul-01-2007 | 904K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
Aug-02-2014
|
12K | |
|
1.0 | English |
Aug-02-2014
|
7K | |
|
1.0 | English |
Aug-02-2014
|
6K | |
|
1.0 | English |
Aug-01-2014
|
257K | |
 |
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0300 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2018. |
| Part Number | ER-OLED1602-4B |
| Display Format | 16x2 Character |
| Interface | I2C, 3-wire SPI, 4-wire SPI, 6800 4-bit Parallel , 6800 8-bit Parallel , 8080 4-bit Parallel , 8080 8-bit Parallel |
| IC or Equivalent | US2066 |
| Appearance | Blue on Black |
| Connection | Soldering FPC |
| Outline Dimension | 68.50(W)x17.50(H)x2.00(T)mm |
| Visual Area | 58.22x14.52mm |
| Active Area | 56.22(W)x11.52(H)mm |
| Dot (Pixel) Size | 0.57x0.67mm |
| Dot (Pixel) Pitch | 0.60x0.70mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 10000:1 |
| Viewing Angle Range | Free |
| Brightness(Typ) | 120cd/m2 |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -40℃~85℃ |
| Storage Temperature | -40℃~90℃ |
