Serial SPI 1.3"128x64 OLED Display Module SSD1306 w/Soldering FPC
- Buy 10 for US$4.61 each and save 3%
- Buy 30 for US$4.49 each and save 5%
- Buy 50 for US$4.36 each and save 8%
- Buy 100 for US$4.24 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
Serial SPI 1.3"128x64 OLED Display Module SSD1306 w/Soldering FPC
US$4.73
-
8051 Microcontroller Development Board for OLED Display ER-OLED013-1
US$51.77
-
Total price
Description
ER-OLED013-1W is the graphic OLED display module made of 128x64 white OLED pixels,diagonal is only 1.3 inch.The controller ic SSD1306, communicates via 6800/8080 8-bit parallel and I2C/3-wire/4-wire serial interface,thanks to controller's built-in voltage generation,only a single 3.3V power supply is needed. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.
The FPC is the soldering type,no need connector.Please check ourER-OLED013A1-1W if you want the single sided type FPC with ZIF connector.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-OLED013-1_Series_Datasheet | English | Mar-05-2012 |
1.2M
|
 |
ER-OLED013-1_3D Model | English | Aug-16-2023 | 300K |
|
Controller IC SSD1306 Datasheet | English |
Nov-01-2014
|
1.1M |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
English |
Jun-18-2010
|
47K | |
|
|
English |
May-16-2013
|
44K | |
|
|
English |
Jun-18-2010
|
44K | |
|
|
English |
Feb-03-2010
|
140K | |
 |
N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0100 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2015. |
| Part Number | ER-OLED013-1W |
| Display Format | 128x64 Pixels (Dots) |
| Interface | I2C, 3-wire SPI, 4-wire SPI, 6800 8-bit Parallel , 8080 8-bit Parallel |
| IC or Equivalent | SSD1306 |
| Appearance | White on Black |
| Diagonal Size | 1.3“ |
| Connection | Soldering FPC |
| Outline Dimension | 34.50(W)x23.00(H)x1.45(T)mm |
| Visual Area | 31.42x16.70mm |
| Active Area | 29.42(W)x14.70(H)mm |
| Dot (Pixel) Size | 0.21x0.21mm |
| Dot (Pixel) Pitch | 0.23x0.23mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 10000:1 |
| Viewing Angle Range | Free |
| Brightness(Typ) | 100cd/m2 |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~85℃ |
-
Alireza Yeganeh
2020-01-19 11:46:12
Does it support DC/DC conversion?
1 answer-
Alireza Yeganeh
2020-01-28 02:30:15
Yes,ER-OLED013-1W this display can support DC/DC conversion.Pls see the details in the datasheet "Controller IC SSD1306 Datasheet" and "
ER-OLED013-1 Series Interfacing Document" on the website.
-
