Red 1.54" inch e-Ink Display w/Arduino Shield,Library 200x200 for ESL
Availability: In stock
US$11.62
- Buy 10 for US$11.31 each and save 3%
- Buy 30 for US$10.99 each and save 5%
- Buy 50 for US$10.70 each and save 8%
- Buy 100 for US$10.40 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
Red 1.54" inch e-Ink Display w/Arduino Shield,Library 200x200 for ESL
US$11.62
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$11.80
-
EANSDI 1GB TF Flash Memory Card Micro SD
US$4.83
-
Total price
Description
ER-EPD0154-2R-5070 is a 1.54 inch e-paper display panel with shield, FFC cable and ZIF connector for arduino due,arduino mega 2560,arduino uno or arduino nano. It comes with SSD1681 controller,200x200 resolution,red/white/black color,compact size,high contrast, sunlight readable.
Package Content
◇ e-Paper Display Panel x 1
◇ Arduino Shield x 1
◇ FFC Cable x 1
◇ ZIF connector x 1
* Please select if you wish to have optional accessories.
Application
◇ Logistics
◇ Reusable Transit Item
◇ Station Terminal
◇ Smart Card
◇ Smart Identity Tag
◇ Seat Number Tab
◇ Smart Luggage Tag
◇ Smart Coffee Cup
◇ Smart Home Application
◇ Identification & Access
◇ Display the Latest Weather Forecast
◇ Display Your Own Twitter Feed
◇ E-paper room booking system
◇ Other IoT (Internet of Things) Devices
◇ 1D/2D Barcode Electronic Shelf Label
Datasheet
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.54 inch E-Paper/E-Ink Display Datasheet | 1.0 | English | May-20-2020 |
689K
|
|
Controller IC SSD1681 Datasheet | 1.0 | English | Jun-05-2019 | 1.78M |
|
Arduino Shield Drawing | 1.0 | English | Jun-14-2019 | 383K |
Tutorial-Arduino
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
Arduino Library and Example for 4-wire SPI and SD Card | 1.0 | English | May-29-2020 | 226K |
|
Arduino Interfacing Document | 1.0 | English | Jul-10-2019 |
160K
|
| Gross Weight (kg) | 0.0400 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2020. |
| Part Number | ER-EPD0154-2R-5070 |
| Display Format | 200x200 Pixels |
| Interface | 3-wire SPI, 4-wire SPI |
| IC or Equivalent | SSD1681 |
| Appearance | Red+Black on White |
| Diagonal Size | 1.54” |
| Connection | Plug-in FPC |
| Outline Dimension | 31.80(W)x37.32(H)x0.9(T)mm |
| Visual Area | 27.00x27.00mm |
| Active Area | 27.00(W)x27.00(H)mm |
| Dot (Pixel) Pitch | 0.135x0.135mm |
| IC Package | COG |
| Display Type | E-Paper |
| Touch Panel Optional | No |
| Sunlight Readable | Yes |
| Viewing Angle Range | Left:85.0 , Right:85.0 , Up:85.0 , Down:85.0 degree |
| Brightness(Typ) | 80cd/m2 |
| Power Supply(Typ) | 3V |
| Operating Temperature | 0℃~40℃ |
| Storage Temperature | -0℃~40℃ |
