ER-TFTMC050-3 is 800x480 pixel 5" color tft lcd display with small controller board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.
It supports 8080 6800 8-bit,16-bit parallel,3-wire,4-wire,I2C serial spi interface.It's optional for resistive touch panel and capacitive touch panel with controller,optional arduino shield with library and example and optional for power supply.
Datasheet for TFT LCD Display,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFTMC050-3_Datasheet | English |
Apr-08-2021 |
5.0M |
 |
ER5517 Controller Board_3D Model | English | Aug-17-2023 | 2.0M |
|
40 Pins 1.0mm Pitch ZIF Connector Drawing | English | Apr-19-2013 | 159K |
Datasheet for Touch Panel,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
5 inch 4-Wire Resistive Touch Panel Datasheet | English | May-13-2013 | 353K |
|
Resistive Touch Panel Controller XPT2046 Datasheet | English | May-08-2007 | 579K |
|
5 inch Capacitive Touch Panel Outline Drawing | English | Jun-07-2017 | 190K |
|
Capacitive Touch Controller GSL1680F Datasheet | English | Jun-07-2017 | 1.1M |
 |
gslX680_311_5_F.h | English | Jun-07-2017 | 113K |
|
sunplus_gslX680.c | English | Jun-26-2015 | 19K |
Datasheet for Schematic And Arduino Shield
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
ER-AS-5517 Datasheet | English | Dec-14-2021 | 1.1M |
|
|
ER-AS-5517 Arduino Schematic Diagram | English | Apr-25-2021 |
243K |
Tutorial - Arduino
It's better to use this program with the arduino shield provided by our company.
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Apr-07-2021 | 8.2M |
Tutorial - 8051
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
Serial/Parallel Interface+Capacitive and Resistive Touch 8051 Interfacing and Demo Code | English | Apr-07-2021 | 3.6M |
| Gross Weight (kg) | 0.1450 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2021. |
| Part Number | ER-TFTMC050-3 |
| Display Format | 800x480 Pixels |
| Interface | I2C, 3-wire SPI, 4-wire SPI, 6800 8-bit Parallel , 6800 16-bit Parallel , 8080 8-bit Parallel , 8080 16-bit Parallel |
| IC or Equivalent | N/A |
| Appearance | RGB |
| Diagonal Size | 5.0“ |
| Connection | Plug-in FFC |
| Outline Dimension | 120.70(W)x75.80(H) |
| Visual Area | 110.70x67.40mm |
| Active Area | 108.00(W)x64.80(H)mm |
| Dot (Pixel) Pitch | 0.135(W)x0.135(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 300cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 15mA |
| Power Supply(Typ) | 3.3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
