Low Cost 1.8 inch TFT LCD Module 128x160 SPI for Arduino,Raspberry Pi
- Buy 10 for US$2.73 each and save 3%
- Buy 30 for US$2.66 each and save 5%
- Buy 50 for US$2.58 each and save 8%
- Buy 100 for US$2.51 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
Low Cost 1.8 inch TFT LCD Module 128x160 SPI for Arduino,Raspberry Pi
US$2.80
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
Total price
Description
ER-TFTM018-5 is 1.8 inch TFT LCD display with breakout board, offering a crisp 128x160 pixel resolution. With an contrast ratio of 300:1 and brightness level of 250cd/m2 ensures clear and vibrant visuals in most environments and it can be effortlessly controlled by a range of MCUs, including 8051, PIC, AVR, ARDUINO, ARM, and Raspberry PI. This module is the perfect choice for embedded systems, industrial devices, security equipment, and handheld devices that demand high-quality and vibrant visuals. It incorporates a hassle-free 4-wire serial SPI interface and is equipped with the ST7735S controller.
For this product, we have also meticulously prepared interfacing documents, libraries, and examples specifically tailored for the Arduino Due, Mega 2560, Uno, Nano, as well as the Raspberry Pi and Raspberry Pi Zero. This ensures seamless integration and easy control for users working with these popular platforms.
Datasheet
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFTM018-5_Datasheet | English | Feb-24-2024 | 1.5M |
|
Controller ST7735S Datasheet | English | Nov-01-2011 | 3.0M |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Feb-24-2024 | 230K |
Tutorial- Raspberry Pi
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
Raspberry Pi Library and Example | English | Feb-24-2024 | 252K |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Feb-24-2024 | 190K |
| Gross Weight (kg) | 0.0270 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2020. |
| Part Number | ER-TFTM018-5 |
| Display Format | 128x160 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | ST7735S |
| Appearance | RGB |
| Diagonal Size | 1.8“ |
| Connection | Pin Header |
| Outline Dimension | 35.00(W)x56.00(H)mm |
| Visual Area | 29.63x36.64mm |
| Active Area | 28.03(W)x35.04(H)mm |
| Dot (Pixel) Pitch | 0.218x0.219mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 300:1 |
| Colors | 4K/65K/262K |
| Viewing Angle Range | Left:60.0 , Right:60.0 , Up:40.0 , Down:50.0 degree |
| Brightness(Typ) | 250cd/m2 |
| Power Supply(Typ) | 3V |
| Operating Temperature | -10℃~60℃ |
| Storage Temperature | -20℃~70℃ |
