IPS 7 inch 1024x600 Display Mini HDMI Board for Raspberry PI
- Buy 10 for US$28.20 each and save 3%
- Buy 30 for US$27.44 each and save 5%
- Buy 50 for US$26.68 each and save 8%
- Buy 100 for US$25.92 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-TFT070A2-6-5782 is an IPS 7" TFT LCD display that comes with a mini HDMI signal driver board, offering a display resolution of 1024x600 pixels. The product also includes an optional 4-wire resistive touch panel with USB driver board and cable, as well as an optional capacitive touch panel with USB controller board and cable.
This display boasts superior quality and full viewing angles, making it ideal for use in embedded systems, cars, industrial devices, security systems, and handheld equipment where high-quality and colorful video displays are required. It is particularly suitable for use with Raspberry Pi via HDMI and supports Raspbian, Ubuntu, WIN10 IOT, multi-touch, and driver-free functionality.
In addition to Raspberry Pi, this product can also be used as a computer monitor and is compatible with Windows 11/10/8/7. It supports multi-touch and driver-free operation, making it a convenient and easy-to-use display solution for a wide range of applications.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 7 Inch 1024x600 Pixels IPS TFT LCD Display | 1 |
| 2 | Mini HDMI Board | 1 |
Datasheet for TFT Display with Video Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT070A2-6-5782 Datasheet | English | Jul-07-2023 | 1.4M |
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-TPC070-8-USB Outline Drawing | English |
May-30-2018
|
277K
|
Datasheet for Resistive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Feb-02-2013
|
247K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.1400 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT070A2-6-5782 |
| Display Format | 1024x600 Pixels |
| Interface | HDMI |
| IC or Equivalent | RTD2660H |
| Appearance | RGB |
| Diagonal Size | 7.0“ |
| Connection | Plug-in FPC |
| Outline Dimension | 164.90(W)x100.00(H)x3.5(T)mm |
| Visual Area | 156.56x88.51mm |
| Active Area | 154.21(W)x85.92(H) |
| Dot (Pixel) Size | 0.150(W)x0.143(H)mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 800:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:65.0 , Down:75.0 degree |
| Brightness(Typ) | 600cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 5V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
