IPS 5" Raspberry Pi Touch Screen TFT LCD Display w/HDMI Driver Board
- Buy 10 for US$26.84 each and save 3%
- Buy 30 for US$26.07 each and save 5%
- Buy 50 for US$25.39 each and save 8%
- Buy 100 for US$24.66 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
IPS 5" Raspberry Pi Touch Screen TFT LCD Display w/HDMI Driver Board
US$27.57
-
AC100-240V To DC 5V 2A Power Supply Adapter for TFT Driving Board
US$3.11
-
Total price
Description
ER-TFT050-6-3938 is a 5 inch IPS TFT LCD display with a resolution of 800x480 pixels. It comes with an small HDMI board and can be used with main development boards such as Raspberry Pi,BeagleBone Black , LattePanda,UDOO,Odroid and etc.
Additionally, it has optional 4-wire resistive touch panel with USB driver board and cable or optional capacitive touch panel with USB controller board and cable, allowing for user input. An optional remote control is also available for convenience.
This display offers superior display quality with a full viewing angle, which makes it suitable for various applications such as industrial control equipment, medical devices, handheld devices, and embedded systems. It can be used for displaying images, text, videos, and other graphical content.
Power adaptor used for this product should be 5V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage.
When lose signal,the screen is blue or black that is available in the menu setting.There is no snowy screen or white noise in setting menu.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 5 inch IPS TFT LCD 800x480 Pixels Display | 1 |
| 2 | Small HDMI Driver Board | 1 |
| 3 | Keyboard Cable with Terminal | 1 |
| 4 | 50 to 40 Pins Adaptor Board | 1 |
| 5 | Power Cable with Terminal | 1 |
Datasheet for TFT LCD Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT050-6-3938 Datasheet | English | Dec-15-2022 | 942K |
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-TPC050-5-USB Outline Drawing | English |
May-30-2018
|
294K
|
Datasheet for Resistive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Mar-02-2013
|
180K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.2050 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT050-6-3938 |
| Display Format | 800x480 Pixels |
| Interface | HDMI |
| IC or Equivalent | RTD2660H |
| Appearance | RGB |
| Diagonal Size | 5.0“ |
| Connection | Plug-in FPC |
| Outline Dimension | 120.70(W)x75.80(H)x2.8(T)mm |
| Visual Area | 110.70x67.40mm |
| Active Area | 108.00(W)x64.80(H)mm |
| Dot (Pixel) Pitch | 0.135(W)x0.135(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 450cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 40mA |
| Power Supply(Typ) | 5V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
