IPS TFT 4.3 inch LCD OPTL TouchScreen Display for MP4,GPS,480x272
- Buy 10 for US$12.13 each and save 3%
- Buy 30 for US$11.80 each and save 5%
- Buy 50 for US$11.48 each and save 8%
- Buy 100 for US$11.11 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
IPS TFT 4.3 inch LCD OPTL TouchScreen Display for MP4,GPS,480x272
US$12.46
-
8051 Microcontroller/MCU Development Board for 4.3 inch TFT Display
US$43.21
-
Total price
Description
ER-TFT043A4-3 is a 4.3 inch IPS TFT display with a resolution of 480x272 pixels. The display has a high contrast ratio of 500:1, making it capable of rendering deep blacks and vibrant colors. It also has a high brightness of 500cd/m2, making it suitable for use in both indoor and outdoor environments.
ER-TFT043A4-3 comes with optional resistive or capacitive touch screen capability, allowing users to interact with the display through touch. The resistive touch screen option allows for precise touch input using a stylus or finger, while the capacitive touch screen option allows for multi-touch input with bare fingers.
Additionally, ER-TFT043A4-3 features an optional Zif connector for FPC, allowing for easy connection to other devices. It is also compatible with the 8051 board, a popular microcontroller board commonly used in embedded systems and arduino shield with the examples and library.
Overall, ER-TFT043A4-3 is a versatile and high-performance display screen that is suitable for a wide range of applications, including industrial control systems, home automation, and portable electronics.
The LED backlight driver IC we suggest to use for this display is PT4110.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 4.3 inch 480x272 Pixels IPS TFT LCD Display | 1 |
Datasheet for TFT LCD Display,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT043A4-3_Datasheet | English | Dec-15-2022 | 938K |
|
Driver IC ST7283_Datasheet | English | Sep-10-2020 | 1.5M |
|
40 Pins 0.50mm Pitch ZIF Connector Drawing | English | Jul-26-2012 | 272K |
Datasheet for Touch Panel,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
4.3 inch 4-Wire Resisitve Touch Panel Datasheet | English | May-13-2013 | 434K |
|
|
4.3 inch Capacitive Touch Panel of Coonector Type FPC Outline Drawing | English | Apr-21-2014 | 190K |
|
|
4.3 inch Capacitive Touch Panel of Soldering Type FPC Outline Drawing | English | Jan-22-2021 | 273K |
|
|
Capacitive Touch Controller FT5206 Datasheet | English | Dec-20-2010 | 751K |
|
|
6 Pins FPC Connector Drawing for Capactive Touch Panel | English | Jul-12-2014 | 179K |
| Gross Weight (kg) | 0.1270 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT043A4-3 |
| Display Format | 480x272 Pixels |
| Interface | RGB |
| IC or Equivalent | ST7283 |
| Appearance | RGB |
| Diagonal Size | 4.3” |
| Connection | Plug-in FPC |
| Outline Dimension | 105.50(W)x67.20(H)x2.9(T)mm |
| Visual Area | 97.04x55.86mm |
| Active Area | 95.04(W)x53.85(H)mm |
| Dot (Pixel) Size | 0.198(W)x0.198(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 500cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 15mA |
| Power Supply(Typ) | 3.3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
