GLCD 128x64 display Graphic LCD Module w/KS0107+KS0108 Black on YG
- Buy 10 for US$10.30 each and save 3%
- Buy 30 for US$10.00 each and save 6%
- Buy 50 for US$9.71 each and save 8%
- Buy 100 for US$9.42 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
GLCD 128x64 display Graphic LCD Module w/KS0107+KS0108 Black on YG
US$10.59
-
8051 Microcontroller Development Board for Graphic LCD ERM12864-2
US$44.75
-
Total price
※ Product Recommendation
We recommend the replacement of ERM12864SYG-2 named ERMC12864SYG-2 that is more cheap ,sufficient stock and the same quality.
Description
ERM12864SYG-2 is yellow green background with 128x64 monochrome dark blue pixels,S6B0107 and S6B0108 controller that is extremely common and well documented,6800 8-bit parallel interface,single led backlight with yellow green color included can be dimmed easily with a resistor or PWM,stn-lcd positive,wide operating temperature range,rohs compliant,compact size.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for Graphic LCD Module,Controller IC
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
128x64 Graphic LCD Module Datasheet | 1.0 | English | Jul-04-2012 |
429K
|
|
Controller IC S6B0107 Datasheet | 1.0 | English | Jun-01-2000 | 142K |
|
Controller IC S6B0108 Datasheet | 1.0 | English | Jun-01-2000 | 109K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
Jun-18-2009
|
45K | |
|
1.0 | English |
Sep-25-2009
|
179K | |
 |
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0970 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2015. |
| Part Number | ERM12864SYG-2 |
| Display Format | 128x64 Pixels (Dots) |
| Interface | 6800 8-bit Parallel |
| IC or Equivalent | S6B0107 , S6B0108 |
| Appearance | Dark Blue on Yellow Green |
| Diagonal Size | 2.9” |
| Connection | Pin Header |
| Outline Dimension | 93.0(W)x70.0(H)x13.0(T)mm |
| Visual Area | 72.00x39.00mm |
| Active Area | 66.52(W)x33.24(H) |
| Dot (Pixel) Size | 0.48x0.48mm |
| Dot (Pixel) Pitch | 0.52x0.52mm |
| IC Package | COB |
| Display Type | STN-LCD Yellow Green |
| Touch Panel Optional | No |
| Sunlight Readable | Yes |
| Viewing Direction | 6:00 |
| Backlight Color | Yellow Green Color |
| Backlight Current (Typ) | 45mA |
| Power Supply(Typ) | 5V |
| Supply Current for LCM(Max) | 6mA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
