Bar Type 2.4 inch 480x640 IPS TFT LCD Display SPI+RGB Interface

Description

ER-TFT024-5 is 2.4 inch IPS TFT display, featuring a sharp resolution of 480x640 pixels. With an impressive contrast ratio of 1000:1, it excels in rendering deep blacks and vibrant colors, ensuring a visually striking experience. The IPS technology allows full viewing angle, It also has brightness of 350cd/m2.

ER-TFT024-5 is built-in ST7701S controller,3-wire SPI and the 18-bit RGB parallel interface are used in a sequence to communicate data to the display. The SPI interface is first used to initialize the display parameters through command registers. Once initialized, the display can receive data over the RGB parallel interface at a higher speed.

We've crafted an optional LT7680 controller board for seamless conversion of the ER-TFT024-5 to a 4-wire SPI interface. Additionally, our optional Arduino shield simplifies connectivity with Arduino boards like Due, Mega, and Uno, eliminating the need for wiring or soldering. No fuss – just plug and play! We've also provided a comprehensive Arduino library and examples for your convenience.

That is suitable for a wide range of applications, including industrial control systems, home automation and portable electronics.

What's included in the package ?

Number	Standard Accessory Name	Quantity
1	2.4 inch 480x640 Pixels TFT LCD Display	1



Datasheet for Display

Format	Documents Name	Language	Update Date	Size
	ER-TFT024-5_Datasheet	English	Nov-01-2024	632K
	Controller ST7701S_Datasheet	English	Apr-09-2017	5.2M

Datasheet for Controller Board

Format	Documents Name	Language	Update Date	Size
	LT7680 Controller Board Outline	English	Jan-03-2024	254K
	Controller LT7680 Datasheet	English	Jul-10-2020	4.2M

Datasheet for Arduino Shield

Format	Documents Name	Language	Update Date	Size
	ER-AS-5517 Datasheet	English	Dec-14-2021	1.1M



Tutorial- Arduino

Format	Documents Name	Language	Update Date	Size
	Arduino Library and Example	English	Nov-10-2024	2.5M



Tutorial - 8051 Microcontroller

Format	Documents Name	Language	Update Date	Size
	Demo Code	English	Nov-10-2024	198K
	8051 Interfacing	English	Jan-26-2024	164K

Tutorial - Initialization

Format	Documents Name	Language	Update Date	Size
	Initialization Program	English	Nov-10-2024	2K
