Description
ER-EPD0213-2B-5070 is a 2.13 inch e-paper display panel with shield, FFC cable and ZIF connector for arduino due,arduino mega 2560,arduino uno or arduino nano. It comes with UC8251 controller,122x250 resolution,white/black color,compact size,high contrast, sunlight readable.
Package Content
◇ e-Paper Display Panel x 1
◇ Arduino Shield x 1
◇ FFC Cable x 1
◇ ZIF connector x 1
* Please select if you wish to have optional accessories.
Application
◇ Logistics
◇ Reusable Transit Item
◇ Station Terminal
◇ Smart Card
◇ Smart Identity Tag
◇ Seat Number Tab
◇ Smart Luggage Tag
◇ Smart Coffee Cup
◇ Smart Home Application
◇ Identification & Access
◇ Display the Latest Weather Forecast
◇ Display Your Own Twitter Feed
◇ E-paper room booking system
◇ Other IoT (Internet of Things) Devices
◇ 1D/2D Barcode Electronic Shelf Label
Datasheet
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-EPD0213-2_Datasheet | English | Aug-13-2024 |
730K
|
![]() |
Controller IC UC8251 Datasheet | English | Nov-22-2019 | 1.M |
![]() |
Arduino Shield Drawing | English | Jun-14-2019 | 383K |
Tutorial-Arduino
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
Arduino Library and Example for 4-wire SPI and SD Card | English | Aug-16-2024 | 32K |
![]() |
Arduino Interfacing Document | English | Jul-10-2019 |
160K
|
Gross Weight (kg) | 0.0360 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
Part Number | ER-EPD0213-2B-5070 |
Display Format | 122x250 Pixels |
Interface | 3-Wire Serial SPI, 4-Wire Serial SPI |
IC or Equivalent | UC8251 |
Appearance | Black on White |
Diagonal Size | 2.13“ |
Connection | Plug-in FPC |
Outline Dimension | 29.20(W)x59.20(H)x1.1(T)mm |
Visual Area | 23.70x48.55mm |
Active Area | 23.70(W)x48.55(H)mm |
Dot (Pixel) Pitch | 0.194x0.194 |
IC Package | COG |
Display Type | E-Paper |
Touch Panel Optional | No |
Sunlight Readable | Yes |
Viewing Angle Range | Left:85.0 , Right:85.0 , Up:85.0 , Down:85.0 degree |
Brightness(Typ) | No |
Backlight Current (Typ) | N/A |
Power Supply(Typ) | 3V |
Operating Temperature | 0℃~50℃ |
Storage Temperature | -25℃~60℃ |
