9" IPS Raspberry Pi Touch Screen 1024x600 Display w/HDMI Driver Board
- Buy 10 for US$39.48 each and save 2%
- Buy 30 for US$38.47 each and save 5%
- Buy 50 for US$37.45 each and save 8%
- Buy 100 for US$36.44 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Attention
All the accessories listed below tier pricing need to pay.We won't deliver until you select. Power adaptor should be 5V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage.The temperature for controller RTD2660 would increase during working.That's normal phenomenon,not quality problem.
When lose signal,the screen is blue or black that is available in the menu setting.There is no snowy screen or white noise in setting menu.
Description
ER-TFT090-3-3938 is IPS 9 " color tft lcd display with small HDMI signal driver board,1024x600 pixels,optional 4-wire resistive touch panel with USB driver board and cable,optional capacitive touch panel with USB controller board and cable. It's superior display quality,wide view angle.
It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video. It's also ideal for Raspberry PI by HDMI.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 9 inch TFT LCD 1024x600 Pixels TFT LCD Display | 1 |
| 2 | Small HDMI Driver Board | 1 |
| 3 | Keyboard Cable with Terminal | 1 |
| 4 | Power Cable with Terminal | 1 |
Datasheet for TFT Display with Video Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT090-3-3938 Datasheet | English |
Aug-29-2022 |
800K
|
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-TPC090-3-USB Outline Drawing | English |
Oct-10-2018
|
274K
|
Datasheet for Resistive Touch Panel,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Apr-21-2015
|
264K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.4250 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2022. |
| Part Number | ER-TFT090-3-3938 |
| Display Format | 1024x600 Pixels |
| Interface | HDMI |
| IC or Equivalent | N/A |
| Appearance | RGB |
| Diagonal Size | 9.0“ |
| Connection | Plug-in FPC |
| Outline Dimension | 211.10(W)x126.5(H)x5.2(T)mm |
| Visual Area | 200.01x117.55mm |
| Active Area | 196.60(W)x114.15(H)mm |
| Dot (Pixel) Size | 0.191(W)x0.190(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 450cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 5V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
