5"TFT LCD Display Capacitive Touchscreen w/RA8875 Controller 800x480
Availability: In stock
US$41.34
- Buy 10 for US$40.29 each and save 3%
- Buy 30 for US$39.14 each and save 5%
- Buy 50 for US$38.11 each and save 8%
- Buy 100 for US$37.02 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
5"TFT LCD Display Capacitive Touchscreen w/RA8875 Controller 800x480
US$41.34
-
New WINBOND IC Chip FLASH 128M BIT W25Q128JV SOP8 Package
US$1.87
-
EANSDI 1GB TF Flash Memory Card Micro SD
US$4.83
-
Total price
Description
ER-TFTM050A2-3-3661 is 800x480 dots 5" color tft lcd display with RA8875 controller board and capacitive touch panel with touch controller,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.
It supports 8080 6800 8-bit,16-bit parallel,3-wire,4-wire,I2C serial spi interface.Built-in MicroSD card slot. It's optional for font chip, flash chip and microsd card. We offer two types connection,one is pinheader and the another is ZIF connector with flat cable mounting on board by default and suggested.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".Here is the link for 5" TFT capacitive touch shield with libraries,examples,schematic diagram for Arduino Due,Mega 2560 and Uno. For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 5 inch TFT LCD Display with RA8875 Controller Board | 1 |
| 2 | 5 inch Capacitive Touch Panel with Touch Controller | 1 |
Datasheet for Display Module
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
ER-TFTM050A2-3-3661 Datasheet | 1.0 | English | Jul-04-2015 |
1.02M
|
 |
ER-TFTM050A2-3-3661_3D Model | 1.0 | English |
Jan-28-2021 |
7.8M |
|
Controller IC RA8875 Datasheet | 1.0 | English | Jul-31-2013 |
4.3M
|
Datasheet for Capacitive Touch Panel,Controller,Connector
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
5 inch Capacitive Touch Panel Outline Drawing | 1.0 | English | Jun-07-2017 | 190K |
|
Capacitive Touch Controller GSL1680F Datasheet | 1.0 | English | Jun-07-2017 | 1.1M |
|
|
6 Pins 0.5mm Pitch ZIF Connector (FPC Connector) Datasheet | 1.0 | English | Jul-12-2014 | 179K |
 |
gslX680_311_5_F.h | 1.0 | English | Jun-07-2017 | 113K |
|
sunplus_gslX680.c | 1.0 | English | Jun-26-2015 | 19K |
Datasheet for Flash Memory,MicroSD Card Slot
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
128M-BIT Flash W25Q128FV Datasheet | 1.0 | English | Oct-01-2012 | 1.0M |
|
MicoSD Card Slot Drawing | 1.0 | English | Dec-12-2013 | 1.2M |
Datasheet for Font Chip
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
1.0 | English |
May-08-2010
|
621K | |
|
1.0 | English |
Mar-27-2014
|
2M | |
|
1.0 | English |
Oct-01-2013
|
688K | |
|
1.0 | English |
Apr-12-2013
|
935K |
Datasheet for ZIF Connector
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
1.0 | English |
Aug-07-2013
|
270K | |
|
1.0 | English |
Aug-07-2013
|
274K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
Dec-12-2013
|
1.52M | |
|
1.0 | English |
May-03-2018
|
386K | |
 |
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.1930 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2018 |
| Part Number | ER-TFTM050A2-3-3661 |
| Display Format | 800x480 Pixels |
| Interface | I2C, 3-wire SPI, 4-wire SPI, 6800 8-bit Parallel , 6800 16-bit Parallel , 8080 8-bit Parallel , 8080 16-bit Parallel |
| IC or Equivalent | RA8875 |
| Appearance | RGB |
| Diagonal Size | 5.0“ |
| Connection | Pin Header, Plug-in FFC |
| Outline Dimension | 132.70W)x75.95(H)mm |
| Visual Area | 110.70x67.40mm |
| Active Area | 108.00(W)x64.80(H)mm |
| Dot (Pixel) Pitch | 0.135(W)x0.135(H)mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K |
| Viewing Angle Range | Left:75.0 , Right:75.0 , Up:75.0 , Down:60.0 degree |
| Brightness(Typ) | 300cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 3.3V, 5V |
| Supply Current for LCM(Max) | 480mA (Vdd=3.3V), 280mA(Vdd=5.0V) |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
