5" IPS LCD Screen TFT Module,800X480 VGA Video AV Driver Board
US$25.51
- Buy 10 for US$24.87 each and save 3%
- Buy 30 for US$24.16 each and save 5%
- Buy 50 for US$23.52 each and save 8%
- Buy 100 for US$22.85 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
5" IPS LCD Screen TFT Module,800X480 VGA Video AV Driver Board
US$25.51
-
AC100-240V To DC 12V 2A Power Supply Adapter for TFT Driving Board
US$3.11
-
Total price
Description
ER-TFT050-6-3208 is 800x480 pixels 5 inch IPS tft lcd display with VGA,Video,AV signal driver board.It has optional 4-wire resistive touch panel with USB driver board and cable or optional capacitive touch panel with USB controller board and cable, allowing for user input. An optional remote control is also available for convenience.
This display offers superior display quality,full viewing angle.It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video.
Power adaptor should be 12V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage.
When lose signal,the screen is blue or black that is available in the menu setting.There is no snowy screen or white noise in setting menu.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 5 inch IPS TFT LCD 800x480 Pixels Display | 1 |
| 2 | Video+VGA Driver Board | 1 |
| 3 | Power Cable with Terminal | 1 |
| 4 | Video Cable with Terminal | 1 |
| 5 | VGA Cable with Terminal | 1 |
| 6 | Keyboard Cable with Terminal | 1 |
Datasheet for TFT LCD Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT050-6-3208_Datasheet | English | Dec-15-2022 |
994K
|
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-TPC050-5-USB Outline Drawing | English |
May-30-2018
|
294K
|
Datasheet for Resistive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Mar-02-2013
|
180K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.2010 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT050-6-3208 |
| Display Format | 800x480 Pixels |
| Interface | Video(CVBS), VGA |
| IC or Equivalent | RTD2660H |
| Appearance | RGB |
| Diagonal Size | 5.0“ |
| Connection | Plug-in FPC |
| Outline Dimension | 120.70(W)x75.80(H)x3.0(T)mm |
| Visual Area | 110.70x67.40mm |
| Active Area | 108.00(W)x64.80(H)mm |
| Dot (Pixel) Pitch | 0.135(W)x0.135(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 450cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 40mA |
| Power Supply(Typ) | 12V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
