4"192x64 LCD Arduino Dot Matrix Display w/KS0107+KS0108 Black on YG
- Buy 10 for US$14.35 each and save 3%
- Buy 30 for US$13.94 each and save 6%
- Buy 50 for US$13.53 each and save 8%
- Buy 100 for US$13.12 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
4"192x64 LCD Arduino Dot Matrix Display w/KS0107+KS0108 Black on YG
US$14.76
-
8051 Microcontroller Development Board for Graphic LCD ERM19264-1
US$44.75
-
Total price
※ Product Recommendation
We recommend the replacement of ERM19264SYG-1 named ERMC19264SYG-1 that is more cheap ,sufficient stock and the same quality.
Description
ERM19264SYG-1 is yellow green background with 192x64 monochrome dark blue pixels,S6B0107 and S6B0108 controller that is extremely common and well documented,6800 8-bit parallel interface,single led backlight with yellow green color included can be dimmed easily with a resistor or PWM,stn-lcd positive,wide operating temperature range,optional FFC connection with ZIF connectors,one connector is soldered on board by default and the another is used for customer's board,RoHs compliant.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
192x64 Graphic LCD Module Datasheet | 1.0 | English | Jul-05-2012 |
423K
|
|
Controller IC S6B0107 Datasheet | 1.0 | English | Jun-01-2000 | 142K |
|
Controller IC S6B0108 Datasheet | 1.0 | English | Jun-01-2000 | 109K |
|
20 Pins 1.00mm Pitch ZIF Connector Drawing | 1.0 | English | Jul-26-2012 | 269K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
Mar-29-2004
|
329K | |
|
1.0 | English |
Sep-25-2009
|
197K | |
 |
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.1200 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2015. |
| Part Number | ERM19264SYG-1 |
| Display Format | 192x64 Dots |
| Interface | 6800 8-bit Parallel |
| IC or Equivalent | S6B0107 , S6B0108 |
| Appearance | Dark Blue on Yellow Green |
| Diagonal Size | 4.0“ |
| Connection | Pin Header, Plug-in FFC |
| Outline Dimension | 130.0(W)x65.0(H)x12.0(T)mm |
| Visual Area | 104.00x39.00mm |
| Active Area | 97.49(W)x32.46(H) |
| Dot (Pixel) Size | 0.458x0.458mm |
| Dot (Pixel) Pitch | 0.508x0.508mm |
| IC Package | COB |
| Display Type | STN-LCD Yellow Green |
| Touch Panel Optional | No |
| Sunlight Readable | Yes |
| Viewing Direction | 6:00 |
| Backlight Color | Yellow Green Color |
| Backlight Current (Typ) | 120mA |
| Power Supply(Typ) | 5V |
| Supply Current for LCM(Max) | 7mA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
