4.3" IPS TFT LCD Arduino Shield w/Tutorial,SSD1963 for Mega/Due
US$33.08
- Buy 10 for US$32.21 each and save 3%
- Buy 30 for US$31.34 each and save 5%
- Buy 50 for US$30.47 each and save 8%
- Buy 100 for US$29.51 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
4.3" IPS TFT LCD Arduino Shield w/Tutorial,SSD1963 for Mega/Due
US$33.08
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
Total price
Description
This arduino shield provides a convenient and effective solution for incorporating the ER-TFT043A4-3-4267 display module that is 4.3 inch IPS TFT lcd display with RA8875 controller board into Arduino projects, providing both touchscreen options and ease of use through our library and examples.
For people who want the same screen but not in a shield, check this.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 4.3 inch IPS TFT LCD Display with SSD1963 Controller Board | 1 |
| 2 | Arduino Shield | 1 |
*The default power supply is 5V and the default interface is 8080 16-bit parallel interface.
Compatible with following Arduino Boards
| Board Name | MCU | I/O |
|---|---|---|
| Arduino MEGA2560 | ATMEGA2560 | 54 |
| Arduino MEGA1280 | ATMEGA1280 | 54 |
| Arduino Due | AT91SAM3X8EA | 54 |
| Arduino Uno | ATMEGA328 | 14 |
Datasheet for Display Module
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT043A4-3-5627_Datasheet | English | Dec-15-2022 | 1.5M |
|
Controller IC SSD1963 Datasheet | English | Apr-01-2012 | 827K |
Datasheet and Schematic for Arduino Shield
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-AS-SSD1963 Datasheet | English | Mar-08-2016 | 767K |
|
ER-AS-SSD1963 Arduino Schematic Diagram | English | Aug-08-2019 | 252K |
Datasheet for Touch Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
4.3 inch Resistive Touch Panel Outline Drawing | English | May-13-2013 | 434K |
|
Resistive Touch Panel Controller XPT2046 Datasheet | English | May-08-2007 | 579K |
|
4.3 inch Capacitive Touch Panel Outline Drawing | English | Apr-14-2015 | 190K |
|
Capacitive Touch Panel Controller FT5206 Datasheet | English | Dec-20-2010 |
751K |
Tutorial - Arduino Due (MEGA 2560)Libraries,Examples
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
4.3"Resistive+Capacitive Touch Shield+SD Card | English | Feb-10-2023 |
1.8M |
| Gross Weight (kg) | 0.2000 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT043A4-3-5627-4124 |
| Display Format | 480x272 Pixels |
| Interface | 6800 8-bit Parallel , 6800 9-bit Parallel , 6800 16-bit Parallel , 8080 8-bit Parallel , 8080 9-bit Parallel , 8080 16-bit Parallel |
| IC or Equivalent | SSD1963 |
| Appearance | RGB |
| Diagonal Size | 4.3” |
| Connection | Pin Header, Plug-in FFC |
| Outline Dimension | 132.70(W)x75.80(H)mm |
| Visual Area | 97.90x56.65mm |
| Active Area | 95.04(W)x53.85(H)mm |
| Dot (Pixel) Size | 0.198(W)x0.197(H)mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 500cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 5V |
| Supply Current for LCM(Max) | 230mA ( VDD=3.3V) / 180mA ( VDD=5.0V) |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
