4.3 inch 800x480 HMI Intelligent Smart UART SPI Touch IPS TFT LCD Display
- Buy 10 for US$28.34 each and save 3%
- Buy 30 for US$27.61 each and save 5%
- Buy 50 for US$26.89 each and save 7%
- Buy 100 for US$26.16 each and save 10%
- Buy 500 or more Quote Request
![](https://www.buydisplay.com/media/page/product/shipping.jpg)
![](https://www.buydisplay.com/media/page/product/shipping-fill.jpg)
![](https://www.buydisplay.com/media/page/product/payment.jpg)
![](https://www.buydisplay.com/media/page/product/payment-fill.jpg)
![](https://www.buydisplay.com/media/page/product/tax-info.jpg)
![](https://www.buydisplay.com/media/page/product/tax-info-fill.jpg)
![](https://www.buydisplay.com/media/page/product/warranty.jpg)
![](https://www.buydisplay.com/media/page/product/warranty-fill.jpg)
![](https://www.buydisplay.com/media/page/product/return-policy.jpg)
![](https://www.buydisplay.com/media/page/product/return-policy-fill.jpg)
![](https://www.buydisplay.com/media/page/product/continulty-supply.jpg)
![](https://www.buydisplay.com/media/page/product/continulty-supply-fill.jpg)
-
This Item:
4.3 inch 800x480 HMI Intelligent Smart UART SPI Touch IPS TFT LCD Display
US$29.07
-
Debugging Board for UART HMI Display
US$3.73
-
EANSDI 1GB TF Flash Memory Card Micro SD
US$4.83
-
Total price
What's HMI/UART Display?
HMI+UART Display is a display solution that combines a human-machine interface with UART communication capabilities.
In addition to a controller,our HMI display also incorporates MCU functionality. The MCU receives commands sent from the main control board (client-side)via a UART interface and then displays text, images, or animations based on these predefined instructions. The MCU on the main control board(client-side) does not require complex programming or execution specifically for image display. You can use our GUI Design software - UI Editor to create text, images, or animations easily. No programming skill is needed.
Features of HMI/UART Display
1-High Quality
ER-TFT043A1-7-5974 is 4.3 inch 800x480 HMI display utilize vivid full-view IPS panels with high- brightness backlight, and for anti-interference purposes, MCU is enclosed within shielding cover.
2-Various Options
If the communication distance is too long for a UART interface, customers can choose RS232 or RS485 communication interfaces instead.
For touchscreens, customers can select from non-touch, resistive touchscreens, and capacitive touchscreens.
We also provide accessories such as louder speakers, rotary encoders, USB cables, SD cards, and debugging boards for customers to choose from.
3-Save Time, Save Cost
Without the need for touchscreen debugging or programming skills, customers can easily create a touch-enabled UI interface with rich graphics and texts using our provided GUI design software- UI Editor to saving customer's development time.
The pricing of this HMI Display is the same as that of a regular LCD module to save cost.
Features of GUI Design Software
Features of our services
1-Free Design UI for Customer
2-Open-source the Projects
![UI for Open-source Project UI for Open-source Project](https://www.buydisplay.com/media/image/UI_Project.gif)
Datasheet
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-TFT043A1-7-5974_Datasheet | English | May-22-2024 | 1.2M |
Datasheet for Touch Panel
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
4.3 inch Resisitve Touch Panel Outline Drawing | English | May-13-2013 | 434K |
![]() |
Resistive Touch Panel Controller XPT2046 Datasheet | English | May-01-2007 | 578K |
![]() |
4.3 inch Capacitive Touch Panel Outline Drawing | English | Apr-21-2014 | 190K |
![]() |
Capacitive Touch Controller FT5206 Datasheet | English | Dec-20-2010 | 751K |
UI Editor
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
UI_Editor-II_V2.30 | English | Jun-03-2024 | 86.1M |
![]() |
UI_Editor-II_User_Manual_V2.30 | English | Jun-03-2024 | 11.6M |
Gross Weight (kg) | 0.1100 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
Part Number | ER-TFT043A1-7-5974 |
Display Format | 800x480 Pixels |
Interface | Serial Uart |
IC or Equivalent | N/A |
Appearance | RGB |
Diagonal Size | 4.3” |
Connection | Female JST SH-Style Cable |
Outline Dimension | 117.50(W)x67.40(H)mm |
Visual Area | 97.22x56.40mm |
Active Area | 95.04(W)x53.86(H)mm |
Dot (Pixel) Pitch | 0.118x0.112mm |
IC Package | SMT |
Display Type | TFT-LCD Color |
Touch Panel Optional | Yes |
Sunlight Readable | No |
Contrast Ratio(Typ) | 500:1 |
Colors | 65K |
Viewing Direction | IPS |
Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
Brightness(Typ) | 350cd/m2 |
Backlight Color | White Color |
Power Supply(Typ) | 5V |
Supply Current for LCM(Max) | 480mA (Vdd=5V) |
Operating Temperature | -20℃~70℃ |
Storage Temperature | -30℃~80℃ |
