4.3 inch 480x800 IPS TFT LCD Display MCU 8080 Interface
- Buy 10 for US$15.92 each and save 3%
- Buy 30 for US$15.49 each and save 5%
- Buy 50 for US$15.06 each and save 8%
- Buy 100 for US$14.63 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-TFT043-9 is a 4.3 inch IPS TFT portrait LCD display with the resolution of 480x800 pixels. The display has a high contrast ratio of 900:1 making it capable of rendering deep blacks and vibrant colors. The IPS technology allows full viewing angle.
The display is built-in NT35510 controller,8080 8-bit/16-bit Parallel interface,wide operating temperature.Optional ZIF connector for FPC allows for easy connection to other devices.
That is suitable for a wide range of applications, including industrial control systems, home automation and portable electronics.
For those who use a 8051 microcontroller, we have also prepared a detailed tutorial that includes interfacing information, demo code, and a development kit. You can find this information at the bottom of the page.We hope that these resources will make it easy for you to get started.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 4.3 inch 480x800 Pixels TFT LCD Display | 1 |
Datasheet for TFT LCD Display,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT043-9 Datasheet | English | Dec-18-2023 | 1.0M |
 |
ER-TFT043-9_3D Model | English |
Jul-16-2024 |
969K |
|
Controller NT35510_Datasheet | English | Nov-08-2010 | 4.6M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Dec-28-2023 | 670K |
| Gross Weight (kg) | 0.0350 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
| Part Number | ER-TFT043-9 |
| Display Format | 480x800 Pixels |
| Interface | 8080 8-bit Parallel , 8080 16-bit Parallel |
| IC or Equivalent | NT35510 |
| Appearance | RGB |
| Diagonal Size | 4.3” |
| Connection | Plug-in FPC |
| Outline Dimension | 60.46(W)x103.65(H)x1.8(T)mm |
| Visual Area | 57.16x94.60mm |
| Active Area | 56.16(W)x93.60(H)mm |
| Dot (Pixel) Pitch | 0.117x0.117mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 900:1 |
| Colors | 65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 280cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
