2 inch 240x296 IPS TFT LCD Display SPI Interface
US$5.53
- Buy 10 for US$5.38 each and save 3%
- Buy 30 for US$5.24 each and save 5%
- Buy 50 for US$5.09 each and save 8%
- Buy 100 for US$4.95 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Description
ER-TFT020-4 is a 2 inch IPS TFT rounded corner LCD display with the resolution of 240x296 pixels. The display has a high contrast ratio of 900:1 making it capable of rendering deep blacks and vibrant colors. The IPS technology allows full viewing angle.
The display is built-in GC9307 controller,4-Wire SPI interface,wide operating temperature.Optional ZIF connector for FPC allows for easy connection to other devices.
That is suitable for a wide range of applications, including industrial control systems, home automation and portable electronics.
For those who use a 8051 microcontroller, we have also prepared a detailed tutorial that includes interfacing information, demo code, and a development kit. You can find this information at the bottom of the page.We hope that these resources will make it easy for you to get started.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 2.0 inch 240x296 Pixels IPS TFT LCD Display | 1 |
Datasheet for TFT LCD Display,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT020-4_Datasheet | English | Dec-18-2023 | 1.0M |
 |
ER-TFT020-4_3D Model | English |
Sep-05-2024 |
641K |
|
Controller GC9307N Datasheet | English | Apr-10-2018 | 5.0M |
|
15 Pins 0.3mm Pitch ZIF Connector Drawing | English | Mar-01-2013 | 390K |
Tutorial - 8051 Microcontroller Demo Code
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Dec-18-2023 | 320K |
| Gross Weight (kg) | 0.0200 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT020-4 |
| Display Format | 240x296 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | GC9307 |
| Appearance | RGB |
| Diagonal Size | 2.0” |
| Connection | Plug-in FPC |
| Outline Dimension | 34.04(W)x43.32(H)x1.8(T) |
| Visual Area | 32.34x39.82mm |
| Active Area | 32.04(W)x39.51(H) |
| Dot (Pixel) Pitch | 0.133x0.133mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 900:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 550cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 80mA |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
