2.1 inch IPS 480x480 Round TFT LCD Display Module for Arduino Due
US$32.35
- Buy 10 for US$31.51 each and save 3%
- Buy 30 for US$30.67 each and save 5%
- Buy 50 for US$29.83 each and save 8%
- Buy 100 for US$29.00 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
2.1 inch IPS 480x480 Round TFT LCD Display Module for Arduino Due
US$32.35
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$11.80
-
EANSDI 1GB TF Flash Memory Card Micro SD
US$4.83
-
Total price
Description
ER-TFT021-1-6011 is a micro round 480x480 pixel 2.1" color IPS tft lcd display panel. With an impressive contrast ratio of 700:1, it excels in rendering deep blacks and vibrant colors, ensuring a visually striking experience. Its exceptional brightness of 300cd/m2 makes it versatile for applications in various lighting conditions, both indoors and outdoors. The IPS technology allows full viewing angle.
We've crafted an LT7680 controller board for seamless conversion of the ER-TFT021-1 to a 4-wire SPI interface. Additionally, our optional Arduino shield simplifies connectivity with Arduino boards like Due, Mega, and Uno, eliminating the need for wiring or soldering. No fuss – just plug and play! We've also provided a comprehensive Arduino library and examples for your convenience.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 2.1" 480x480 TFT Display with Capacitive Touch Panel | 1 |
| 2 | LT7680 Controller Board with FFC Cable | 1 |
| 3 | 20 Pin 1.0mm Pitch ZIF Connector | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT021-1-6011_Datasheet | English | Jul-24-2024 | 777K |
 |
ER-TFT021-1-6011_3D Model | English |
Sep-05-2024 |
4.0M |
|
Controller ST7701S_Datasheet | English | Apr-09-2017 | 5.2M |
|
Capacitive Touch Panel Controller FT3267 Datasheet | English | Jul-24-2015 | 437K |
Datasheet for Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
LT7680 Controller Board Outline | English | Jan-03-2024 | 254K |
|
Controller LT7680 Datasheet | English | Jul-10-2020 | 4.2M |
Datasheet for Arduino Shield
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
ER-AS-5517 Datasheet | English | Dec-14-2021 | 1.1M |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Aug-15-2024 | 1.6M |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English | Aug-15-2024 | 333K |
| Gross Weight (kg) | 0.0440 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
| Part Number | ER-TFT021-6011 |
| Display Format | 480x480 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | LT7680 |
| Appearance | RGB |
| Diagonal Size | 2.1“ |
| Connection | Plug-in FPC |
| Outline Dimension | 59.26(W)x61.27(H)mm |
| Visual Area | Ø 52.88mm |
| Active Area | 53.28(W)x53.28(H)mm |
| Dot (Pixel) Pitch | 0.11x0.11mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 700:1 |
| Colors | 65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 300cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | N/A |
| Power Supply(Typ) | 2.8V |
| Supply Current for LCM(Max) | 160mA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
