Description
ER-TFT101B4-1-5553 is 1024x600 Pixels 10.1 inch color ips tft lcd display module with LT7683 controller board, full viewing angle,very high contrast and brightness,superior display quality and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.
It supports 8080 6800 8-bit,16-bit parallel,3-wire,4-wire,I2C serial spi interface.Built-in MicroSD card slot.It's optional for touch panel controller,4-wire resistive touch panel screen. font chip, flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested.
Also we design the arduino shield for this module,so the customers can easily connect this module with arduino Mega2560 or Uno board through shield.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".Here is the link for 10.1"TFT Touch Shield with Libraries, Examples.Schematic Diagram for Arduino Due,Mega 2560,Uno. For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.
Datasheet for Display Module
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-TFT101B4-1-5553_Datasheet | English | Jul-24-2024 |
2.2M
|
![]() |
ER-TFTM101-1_3D Model | English |
Jan-28-2021 |
9.5M |
![]() |
Controller LT7683 Datasheet | English | Jul-10-2020 | 4.8M |
Datasheet for Touch Panel
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
10.1 inch 4-Wire Touch Panel Datasheet | English | Apr-21-2015 | 235K |
![]() |
10.1 inch Capacitive Touch Panel with Controller Outline | English |
Apr-12-2018
|
283K |
![]() |
Capacitive Touch Controller GT9271 Datasheet | English | Nov-11-2014 | 1.65M |
Datasheet for Flash Memory,MicroSD Card Slot
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
128M-BIT Flash W25Q128FV Datasheet | English | Oct-01-2012 | 1.0M |
![]() |
MicoSD Card Slot Drawing | English | Dec-12-2013 | 1.2M |
Datasheet for ZIF Connector
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
English |
Aug-07-2013
|
270K | |
![]() |
English |
Aug-07-2013
|
266K | |
![]() |
English |
Apr-19-2013
|
268K |
Tutorial- Arduino
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
English |
Aug-15-2024
|
9.5M |
*When used with arduino shield, the SD card should be inserted into the arduino shield's card slot, not the module's card slot.
Tutorial- 8051 Microcontroller
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
English |
Aug-15-2024
|
4.2M |
Gross Weight (kg) | 0.6500 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
Part Number | ER-TFT101B4-1-5553 |
Display Format | 1024x600 Pixels |
Interface | I2C, 3-Wire Serial SPI, 4-Wire Serial SPI, 6800 8-bit Parallel , 6800 16-bit Parallel , 8080 8-bit Parallel , 8080 16-bit Parallel |
IC or Equivalent | LT7683 |
Appearance | RGB |
Diagonal Size | 10.1“ |
Connection | Pin Header, Plug-in FFC |
Outline Dimension | 248.50(W)x145.50(H)mm |
Visual Area | 226.40x128.70mm |
Active Area | 222.72(W)x125.28(H)mm |
Dot (Pixel) Pitch | 0.2175(W)x0.2088(H)mm |
IC Package | SMT |
Display Type | TFT-LCD Color |
Touch Panel Optional | Yes |
Sunlight Readable | No |
Contrast Ratio(Typ) | 800:1 |
Colors | 65K/262K/16.7M |
Viewing Direction | IPS |
Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
Brightness(Typ) | 600cd/m2 |
Backlight Color | White Color |
Backlight Current (Typ) | N/A |
Power Supply(Typ) | 3.3V, 5V |
Supply Current for LCM(Max) | 1000mA (VDD=3.3V),650mA (VDD=5.0V) |
Operating Temperature | -20℃~70℃ |
Storage Temperature | -30℃~80℃ |
