10.1 inch 1024x600 IPS TFT LCD Display High Brightness,Full Viewing Angle
- Buy 10 for US$29.42 each and save 3%
- Buy 30 for US$28.61 each and save 5%
- Buy 50 for US$27.83 each and save 8%
- Buy 100 for US$27.03 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
10.1 inch 1024x600 IPS TFT LCD Display High Brightness,Full Viewing Angle
US$30.21
-
8051 Microcontroller/MCU Development Board for TFT LCD ER-TFT101-1
US$65.94
-
Total price
Description
ER-TFT101B4-1 is a 10.1 inch IPS TFT display with the resolution of 1024x600 pixels. The display has a high contrast ratio of 800:1 making it capable of rendering deep blacks and vibrant colors. It also has a very high brightness of 600cd/m2 making it suitable for use in both indoor and outdoor environments.The IPS technology allows full viewing angle.
ER-TFT101B4-1 comes with optional resistive or capacitive touch screen capability, allowing users to interface with the display through touch. The resistive touch screen option allows for precise touch input using a stylus or finger, while the capacitive touch screen option allows for multi-touch input with bare fingers.
It can be used in any embedded systems,consumer electronics,car,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".Here is the link for 10.1"TFT Touch Shield with Libraries, Examples.Schematic Diagram for Arduino Due,Mega 2560,Uno and 8051 Microcontroller Development Board&Kit.
The LED backlight driver IC we suggest to use for this display is PT4110.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 10.1 inch 1024x600 Pixels IPS TFT LCD Display | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT101B4-1_Datasheet | English |
Jul-24-2024 |
896K |
 |
ER-TFT101B4-1_3D Model | English |
Sep-05-2024 |
823K |
|
Driver IC (HX8282) Datasheet | English | Apr-01-2010 | 2.0M |
|
Driver IC (HX8696) Datasheet | English | Aug-01-2010 | 725K |
|
50 Pins 0.50mm Pitch ZIF Connector Drawing | English | Jul-26-2012 | 273K |
|
2 Pins 3.5mm Pitch SMD Horizontal Backlight Connector Drawing | English | Sep-28-2011 | 360K |
Datasheet for Touch Panel,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
10.1 inch 4-Wire Touch Panel Datasheet | English | Apr-21-2015 | 235K |
|
|
4 Pins 1.0mm Pitch ZIF Connector Drawing for Touch Panel | English | Jul-26-2012 | 268K |
|
|
10.1 inch Capacitive Touch Panel with Controller Outline | English | Apr-12-2018 | 283K |
|
|
Capacitive Touch Controller GT9271 Datasheet | English | Nov-11-2014 | 1.65M |
|
|
6 Pins 0.5mm Pitch ZIF Connector (FPC Connector) Datasheet | English | Jun-10-2014 | 272K |
| Gross Weight (kg) | 0.5550 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
| Part Number | ER-TFT101B4-1 |
| Display Format | 1024x600 Pixels |
| Interface | RGB |
| IC or Equivalent | HX8282, HX8696 |
| Appearance | RGB |
| Diagonal Size | 10.1“ |
| Connection | Plug-in FPC |
| Outline Dimension | 235.0(W)x143.0(H)X5.0(T)mm |
| Visual Area | 226.40x128.70mm |
| Active Area | 222.72(W)x125.28(H)mm |
| Dot (Pixel) Size | 0.2175(W)x0.2088(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 800:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 600cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 200mA |
| Power Supply(Typ) | 3.3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
