1.69 inch 280x240 IPS TFT LCD Display Module for Arduino,Raspberry PI
- Buy 10 for US$5.31 each and save 3%
- Buy 30 for US$5.16 each and save 5%
- Buy 50 for US$5.02 each and save 8%
- Buy 100 for US$4.88 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
1.69 inch 280x240 IPS TFT LCD Display Module for Arduino,Raspberry PI
US$5.45
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
Total price
Description
ER-TFTM1.69-1-SPI is 240x280 pixel 1.69 inch IPS tft lcd display with ST7789V controller and breakout board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It's 4-wire serial spi interface with pin header connection.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,nano and for raspberry pi or raspberry pi zero.For 8051 microcontroller user,we also prepared the interfacing document and demo code.
Datasheet for TFT LCD Module,Controller IC
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
1.69 inch TFT LCD Display Module with Breakout Board Datasheet | English |
Feb-22-2022 |
985K |
|
Controller ST7789VW Datasheet | English | Sep-01-2017 | 3.2M |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Feb-28-2022 | 1.0M |
Tutorial- Raspberry Pi
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
Raspberry Pi Library and Example | English | Feb-28-2022 | 1.7M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Feb-28-2022 | 277K |
| Gross Weight (kg) | 0.0180 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2022. |
| Part Number | ER-TFTM1.69-1-SPI |
| Display Format | 240x280 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | ST7789 |
| Appearance | RGB |
| Diagonal Size | 1.69“ |
| Connection | Pin Header |
| Outline Dimension | 31.00(W)x48.72(H)mm |
| Visual Area | 28.97x33.63mm |
| Active Area | 27.97(W)x32.63(H)mm |
| Dot (Pixel) Pitch | 0.11x0.11mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 480cd/m2 |
| Power Supply(Typ) | 3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
