QSPI 1.32" Color 360x360 Round Circle Screen IPS TFT Display Panel GC9C01
- Buy 10 for US$6.98 each and save 3%
- Buy 30 for US$6.79 each and save 5%
- Buy 50 for US$6.60 each and save 8%
- Buy 100 for US$6.41 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
QSPI 1.32" Color 360x360 Round Circle Screen IPS TFT Display Panel GC9C01
US$7.16
-
8051 Microcontroller/MCU Development Board for TFT LCD ER-TFT1.32-1
US$22.26
-
Total price
Description
ER-TFT1.32-1 is an 1.32 inch IPS TFT display panel featuring a resolution of 360x360 pixels. It utilizes the GC9C01 display driver IC and a QSPI interface for communication.
This display panel is circular in shape with a diameter of 1.32 inches, making it ideal for use in wearables, smartwatches, and other compact devices that require a small, circular display.
The IPS (In-Plane Switching) technology used in this display provides wide viewing angles and excellent color reproduction, making it easy to view from various angles without distortion. The display has a high contrast ratio of 500:1, making it capable of rendering deep blacks and vibrant colors. It also has a high brightness of 450cd/m2.
For your convenience, we have alos prepared optional connectors for you to use.
For those who use a 8051 microcontroller, we have also prepared a detailed tutorial that includes interfacing information, demo code, and a development kit. You can find this information at the bottom of the page.We hope that these resources will make it easy for you to get started.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 1.32" IPS 360x360 Pixels TFT LCD Display | 1 |
Datasheet for TFT LCD Display,IC Controller, Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT1.32-1_Datasheet | English | Dec-15-2022 | 953K |
|
Controller GC9C01 Datasheet | English | Sep-15-2020 | 5.8M |
|
24 Pins 0.4mm Pitch ZIF Connector Drawing | English | Sep-18-2013 | 1.0M |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Feb-10-2023 | 280K |
 |
8051 Microcontroller Development Kit for ER-TFT1.32-1 | N/A | N/A | N/A |
| Gross Weight (kg) | 0.0200 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT1.32-1 |
| Display Format | 360x360 Pixels |
| Interface | QSPI |
| IC or Equivalent | GC9C01 |
| Appearance | RGB |
| Diagonal Size | 1.32" |
| Connection | Plug-in FPC |
| Outline Dimension | 35.88(W)x38.44(H)x1.5(T) |
| Visual Area | Ø34.48mm |
| Active Area | Ø33.48 |
| Dot (Pixel) Pitch | 0.0.93x0.0.93mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 450cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 30mA |
| Power Supply(Typ) | 3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
