1.3" TFT IPS LCD Display Module 240x240 SPI for Arduino Raspberry Pi
- Buy 10 for US$4.61 each and save 3%
- Buy 30 for US$4.49 each and save 5%
- Buy 50 for US$4.36 each and save 8%
- Buy 100 for US$4.24 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
1.3" TFT IPS LCD Display Module 240x240 SPI for Arduino Raspberry Pi
US$4.73
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
Total price
Description
ER-TFTM013-1 is 240x240 pixel 1.3 inch IPS tft lcd display panel with ST7789 controller and breakout board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM. It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It's 4-wire serial spi interface with pin header connection.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM .It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,nano and for 8051 microcontroller user,we also prepared the interfacing document and demo code.
Datasheet for TFT LCD Module,Controller IC
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.3" TFT LCD Display Module with Breakout Board Datasheet | 1.0 | English |
Dec-02-2019 |
910K |
|
Controller ST7789VW Datasheet | 1.0 | English | Sep-01-2017 | 3.2M |
Tutorial- Arduino
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
Arduino Library and Example | 1.0 | English | Dec-10-2019 | 220K |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | 1.0 | English | Oct-29-2018 | 46K |
| Gross Weight (kg) | 0.0220 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
| Part Number | ER-TFTM013-1 |
| Display Format | 240x240 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | ST7789 |
| Appearance | RGB |
| Diagonal Size | 1.3“ |
| Connection | Pin Header |
| Outline Dimension | 27.78(W)x39.22(H)mm |
| Visual Area | 24.40x24.40mm |
| Active Area | 23.40(W)x23.40(H)mm |
| Dot (Pixel) Pitch | 0.097x0.097mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 250cd/m2 |
| Power Supply(Typ) | 3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
-
Paul Kleissler
2020-05-08 21:07:02
What is the pinout of the 12 pin ribbon from the LCD?
1 answer-
Janice Lee
2020-05-09 04:47:22
Dear Customer,
Here is the pin configuration for LCD display screen, pls refer to.
Pin1 - GND
Pin2 - LEDK
Pin3 - LEDA
Pin4 - VDD
Pin5 - GND
Pin6 - GND
Pin7 - D/C
Pin8 - CS
Pin9 - SCL
Pin10 - SDA
Pin11 - RES
Pin12 - GND
Thanks.
-
-
Paul Kleissler
2020-05-08 20:16:36
Can you please tell me the settings of the interface bits IM0 thru IM3. I am having a trouble getting the display to respond to commands.
1 answer-
Janice Lee
2020-05-09 04:40:27
Dear Customer,
Pls note the pins IM0,IM1,IM2,IM3 has not been came out from TFT display and breakout board as they're designed 4SPI interface I by internally and the settings are 0,1,1,0. We guessed that the problem is from somewhere else if the display doesn't work, pls double check your hardware connection and software code. Thanks.
-
