0.71 inch IPS TFT LCD Display 160x160 Round Circle Screen for Smart Watch
- Buy 10 for US$2.11 each and save 2%
- Buy 30 for US$2.05 each and save 5%
- Buy 50 for US$1.99 each and save 8%
- Buy 100 for US$1.94 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
0.71 inch IPS TFT LCD Display 160x160 Round Circle Screen for Smart Watch
US$2.16
-
8051 Microcontroller/MCU Development Board for TFT LCD ER-TFT0.71-1
US$58.00
-
Total price
Description
ER-TFT0.71-1 is 0.71 round circle screen ips tft lcd display, featuring a sharp resolution of 160x160 pixels. With an impressive contrast ratio of 1200:1, it excels in rendering deep blacks and vibrant colors, ensuring a visually striking experience.The IPS technology allows full viewing angle.its brightness level of 350cd/m2 ensures clear and vibrant visuals even in brightly lit environments. It is equipped with the GC9D01 controller. It features a 4-wire SPI interface that ensures stable and efficient data transmission and a soldering type FPC that eliminates the need for an FPC connector, simplifying the installation process.
It's suitable for smartwatches, fitness trackers, and health monitoring devices in wearable technology and blood pressure monitors, glucose meters, and patient monitoring systems in medical technology.
For users of the 8051 microcontroller, we have carefully prepared a comprehensive interfacing document, demonstration code, and an 8051 development board specifically tailored for this display.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 0.71 inch 160x160 Pixels IPS TFT LCD Display | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TF0.71-1_Datasheet | English | Mar-26-2025 | 677K |
|
Controller GC9D01_Datasheet | English | Apr-08-2021 | 34M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Mar-29-2024 | 370K |
 |
N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0180 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2025. |
| Part Number | ER-TFT0.71-1 |
| Display Format | 160x160 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | GC9D01N |
| Appearance | RGB |
| Diagonal Size | 0.71“ |
| Connection | Soldering FPC |
| Outline Dimension | 20.12(W)x22.30(H)x1.8(T)mm |
| Visual Area | 18.76x19.00mm |
| Active Area | 17.76(W)x18.00H)mm |
| Dot (Pixel) Pitch | 0.11x0.11mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 1200:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 350cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 20mA |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
